Overview
This 15mm thickness aluminum alloy heatsink (C519) is specially designed for Raspberry Pi Compute Module 5 CM5 Motherboard. Made with high-quality aluminum alloy materials, it provides efficient heat dissipation, keeping your device cool even during intensive use. Increase the lifespan of your Raspberry Pi with this essential accessory.
It is an efficient, silent and easy-to-install cooling solution for users seeking stability and flexibility.
Test Data
- Test Method: We conducted a quad-core stress test on the C519 at room temperature of 23.2 degrees Celsius. Test script reference to Geekworm test script
- Test result reference to: File:Cpu temp C519.log
- Test Conclusion: In a ventilated environment, C519 can meet the heat dissipation requirements of CM5 under heavy load.
Features
- Model: C519
- Precision Fit: Designed exclusively for the Raspberry Pi Compute Module 5 only.
- Wave-shaped Cooling Fins: 14pcs 10mm thickness wave-shaped cooling fins, maximizes heat dissipation for stable and reliable performance.
- Fanless Design: Ensures silent, noise-free performance without fan life issues
- Support Fan Expansion: Fan mounting holes are reserved for fan installation to further improve the heat dissipation effect.
- Wireless Cutout design: Reserved cutouts to reduce WiFi interference and facilitate antenna connection.
- Premium Build: Constructed from durable and thermally conductive aluminum.
- Easy Installation: No complicated tools required – simply install and secure.
- Compact Design: Space-efficient, without blocking any essential components
- Wide Application: Compatble with official Raspberry Pi IO board, Geekworm X1500 / X1501 IO Carrier Board
- Dimension: 45x55x15 mm / 1.77x2.17x0.59 inch
- Net weight: 42g/ 0.09 lb
Packing List
- 1x C519 15mm thickness heatsink for CM5
- 1x Screws Pack Accessories
Installation Guide
FAQ
Expand
Q1: Question 1
